Multiple distributor for bottles

NX26.1, Bohlender

Material: PTFE, screw cap made of PPS, stopcocks (optional) with cock plug made of FEP. Connections with UNF 1 / 4 ″ 28G internal thread on top and bottom for attaching connecting hoses. Freely rotatable distributor element, cap can be screwed on and off without twisting the hoses. Excellent chemical resistance, Temperature stability -50 to +200 °C. HPLC cap BOLA GL 45 Connections without stopcocks Delivery without connecting hoses, please order separately.

KE52.1, Dwk Life Sciences

Material: PP. Autoclavable: yes. GLS 80 screw cap with four GL 18 threaded necks. Suitable for the transfer of liquids, e.g. for loading HPLC machines with solvents or for use in titration systems. Also usable as a Woulff bottle. Hoses with an outer Ø of between 3.2 and 12.0 mm can be attached to the multiple distributor for bottles by means of GL 18 laboratory screw joints. Multiple distributor for bottles GLS 80 Insert and screw cap made of PP Temperature stability -40 to +140 °C. Delivery without bottles, laboratory screw joints and pressure equalisation set; please order separately.

KKL7.1, Bohlender

Screw cap made of PTFE glass fibre Suitable for barrels and bins with internal thread. Movable distributor body with GL connecting necks made of PTFE. Very high chemical resistance since medium only comes into contact with PTFE. Temperature-stable from -20 °C to +200 °C. Pressure-stable up to max. 1 bar, suitable for use in a vacuum. Application For drawing and filling aggressive or pure liquids and for inserting hoses, tubes and probes into barrels. Multiple distributor for barrels BOLA For Mauser 2″ barrel inner thread Delivery without HT laboratory screw joints with GL thread, please order separately.

NX21.1, Bohlender

Material: PTFE, screw cap made of PPS, stopcocks (optional) with cock plug made of FEP. Connections with UNF 1 / 4 ″ 28G internal thread on top and bottom for attaching connecting hoses. Freely rotatable distributor element, cap can be screwed on and off without twisting the hoses. Excellent chemical resistance, Temperature stability -50 to +200 °C. HPLC cap BOLA GL 45 Connections without stopcocks Delivery without connecting hoses, please order separately.

3HCN.1, Bohlender

Material: PTFE, PFA, PP. Autoclavable: yes. Screw cap made of PP for S 55 threads with freely rotating distributor element made of PTFE. Available with 3, 2 or 4 capillary connections with UNF 1 / 4 ″ 28G internal thread for connecting PFA fittings for capillary hoses (external Ø1.6 mm (green)/2.2 mm (purple)/3.2 mm (yellow)). With PFA dummy stopper (white) to seal capillary connections that are not needed. Depending on the version with hose connectors (NPT 1 / 8 ″ thread) for hoses with internal Ø 5.5-8 mm. 1 x connection (GL 14 thread) for screwing in a b.safe exhaust air filter. Temperature resistance: 0 to +110 °C. For safe disposal of waste solvents without leaks of harmful solvent vapours Freely rotating distributor body, prevents the hoses from twisting when replacing the collecting bottle Using the fittings, hoses can be easily introduced into the collection container; conical nipple clamps the hose and reliably seals at the connection Larger quantities of fluid can optionally be disposed of by connecting hoses with internal Ø5.5-8 mm, via the hose connector connections Suitable exhaust air filter available as an option; its activated carbon filling binds harmful solvent vapours HPLC screw cap b.safe Waste Cap, S 55 Type A: 3 x capillary connection (UNF 1 / 4 ″ 28G), 1 x exhaust air filter connection (GL 14) Delivery incl. PFA fittings: 3 x 1.6 mm, 3 x 2.2 mm, 3 x 3.2, 2 x PFA dummy stopper. Delivery without exhaust air filter, please order separately.

NX23.1, Bohlender

Material: PTFE, screw cap made of PPS, stopcocks (optional) with cock plug made of FEP. Connections with UNF 1 / 4 ″ 28G internal thread on top and bottom for attaching connecting hoses. Freely rotatable distributor element, cap can be screwed on and off without twisting the hoses. Excellent chemical resistance, Temperature stability -50 to +200 °C. HPLC cap BOLA GL 45 Connections with stopcocks Delivery without connecting hoses, please order separately.

NX28.1, Bohlender

Material: PTFE, screw cap made of PPS, stopcocks (optional) with cock plug made of FEP. Connections with UNF 1 / 4 ″ 28G internal thread on top and bottom for attaching connecting hoses. Freely rotatable distributor element, cap can be screwed on and off without twisting the hoses. Excellent chemical resistance, Temperature stability -50 to +200 °C. HPLC cap BOLA GL 45 Connections with stopcocks Delivery without connecting hoses, please order separately.

KKL6.1, Bohlender

Screw cap made of PTFE glass fibre Suitable for barrels and bins with internal thread. Movable distributor body with GL connecting necks made of PTFE. Very high chemical resistance since medium only comes into contact with PTFE. Temperature-stable from -20 °C to +200 °C. Pressure-stable up to max. 1 bar, suitable for use in a vacuum. Application For drawing and filling aggressive or pure liquids and for inserting hoses, tubes and probes into barrels. Multiple distributor for barrels BOLA For barrel inner thread R2″/G2″/BSP 2″ Delivery without HT laboratory screw joints with GL thread, please order separately.

1HPC.1, Bohlender

Material: PPS, PTFE, PFA. Autoclavable: yes. Screw cap for GL 45 bottle thread made of PPS with freely rotating distributor body made of PTFE, selectable with two, three or four connections. Connections with UNF 1 / 4 ″ 28G inner thread for connecting PFA-fittings for hoses (external diameter 3.2 mm), PFA dummy stoppers for the closure of unnecessary connections or a venting valve with change indicator. Temperature resistance: -20 to +200 °C. For removing solvents for HPLC Freely rotating distributor bodies, prevents the hoses twisting when replacing the bottle Using the fittings, hoses can be introduced up to the base of the bottle; conical nipple clamps the hose and seals reliably at the connection The venting valve is specially adapted to the flow rates in HPLC; integrated non-return valve prevents the evaporation of solvents and lets ambient air flow into the bottle in the event of a vacuum. The upstream membrane made of porous PTFE effectively keeps out dirt particles and other contaminations from outside Venting valve with change indicator after activation at the press of a button and with labelling area HPLC screw cap b.safe GL 45 with two connections Delivery incl. 1 x fitting (PFA) and 1 x venting valve with change indicator.

1HT0.1, Bohlender

Material: PPS, PP, PFA. GL 45 flushing bottle distributor made of PPS, GLS 80 flushing bottle distributor made of PP. Each with freely rotating distributor head made of PP with four side connections (GL 45) appropriate for HPLC GL 45 b.safe screw caps. Distributor heads are additionally provided with three central capillary openings each (UNF 1 / 4 ″ 28G). Temperature resistance: 0 to +110 °C. Application: Flushing the HPLC system without contamination or loss of solvents. For this, a distributor head is placed on a flushing bottle, the HPLC b.safe screw caps are removed from the eluent bottles and these are installed on the connections of the flushing bottle distributor. Passage at the distributor neck is sufficiently measured so that the capillary hoses installed on the HPLC screw cap along with filter can be introduced into the flushing bottle. With the GL 45 flushing bottle distributor, the use of intake filters that are as small as possible (max. Ø 14 mm) makes introducing the capillaries through the bottle neck easier. Should a connection of the flushing bottle distributor not be used, this can be closed with a GL 45 screw cap. The escape of solvent vapours that are hazardous to health or a contamination of the flushing solution with ambient air is prevented by the HPLC b.safe screw caps with venting valve. In addition, the flushing bottle distributor can also be used directly for rear flask and needle seat flushing. For this, connect the desired capillaries and a venting valve to the central capillary connections using fittings. HPLC flushing bottle distributor b.safe Delivery incl. 3 x PFA dummy stoppers (white).

NX57.1, Bohlender

Material: PTFE. Filter cartridge holder with UNF 1 / 4 ″ 28G internal thread with replaceable filter cartridge made of porous PTFE. Protects HPLC-systems, pumps, seals, pistons and membranes against contamination by particles or crystallising residues. Filter-Ø 14 mm. Filter length 25 mm. HPLC intake filter BOLA Delivery without connecting hose (Art. No. NX29.1 ff or . NX34.1 ff); please order separately.

HX90.1, Dwk Life Sciences
