Syringe filters CHROMAFIL ® PTFE, 0,45 µm, 3 mm, 100 unit(s)

Produced for stability across temperature-sensitive applications, the Syringe Filters Chromafil ® Ptfe, 0.45 µm, 3 mm, 100 Units offer a compact design with a 6 mm housing made of polypropylene (PP), ensuring minimal extractable substances and excellent chemical resistance. These non-sterile syringe filters feature a hydrophobic PTFE membrane with a pore size of 0.45 µm, suitable for a wide range of liquid and gas filtration tasks, including chromatography techniques such as HPLC, GC, ICP, AAS, TOC, DOC, IR, NMR, photometry, spectroscopy, among others. With a filtration area of 0.07 cm² and a dead volume of approximately 5 µl, these filters can handle samples up to 1 ml while maintaining a maximum operating pressure of 6 bar and a maximum application temperature of 55 °C. The filters come equipped with Luer lock connectors for the inlet and Luer connections for the outlet, making them easy to integrate into various systems.

• Category: Syringe filters
• Membrane material: hydrophobic PTFE
• Sample volume: ≤1 ml
• Sterility: Non-sterile
• Outlet connection: Luer
• Inlet connection: Luer lock connector
• Housing material: PP
• Pore size: 0,45 µm
• Max. application temperature: 55 °C
• Ø membrane: 3 mm
• Dead volume: ~5 µl
• Filtration area: 0.07 cm²
• Ø housing: 6 mm
• Max. operating pressure: 6 bar
• Type: O-45/3
